CEN0004 - 232 AC/DC Clamp Meter (True RMS)

4 Digital Display.
TRUE RMS.
Autoranging.
Auto Power Off.
Peak Hold Function.
Data Hold Function.
Auto Zero.

232 is used in power system maintenance. Beside power measurement, it also provides the voltage, current measurement and continuality function.
Features:

4 Digital Display.
TRUE RMS.
Autoranging.
Auto Power Off.
Peak Hold Function.
Data Hold Function.
Auto Zero.

Specifications:

Standard Accessories:
Bettery, Operation Manual, Carrying Case, Test Lead.

SEW0013 - 2660 CL AC/DC DIGITAL CLAMP METER (AUTO RANGE) 600 ACA/DCA

Description: 2660 CL

FEATURES

4000 - count LCD.

Full automatic measurement, Voltage measurement, Current measurement, Resistor measurement, Frequency counter, Capacitor measurement.

Bargraph indication.

Range change function.

Data Hold function feezes the reading.

REL function.

Peak function.

VAHz mode measures frequency in ACV and ACA mode.

Diode measurement.

Max/Min function.

Continuity check.

Low battery indication.

Auto Power Off (APO) function.

Safety design throughout with no exposed metal parts, shielded banana plugs and recessed input terminals.

Meets : EN 61010-1 CAT III 300V, EN 61010-2-032, EN 61326-1

Dimensions : 210(L) x 90(W) x 40(H) mm

Weight : Approx. 330g (battery included)

Power Source : One type PP3, 6F22, 006P (or equivalent), 9V manganese.

Battery Life : Approx. 100 hours on continuous. (Alkaline)

Accessories : Test leads, carrying case, instruction manual battery (one 006P 9V).

Conductor size : Approx. 35mm max.

Operating principle : Dual slope integration.

Over range indicaton : "O.L" indicated

Low battery indication : sign appears on the display when the battery voltage drops below actcurate operating level.

Response time : Approx. 1 second.

Sample rate : Approx. 2 times per second.

Temperature & humidity for guaranteed : 0 degree C to 50 degree C 80% max.

Storage temperature & humidity : -10 degree C to 60 degree C 80% max.

SPECIFICATIONS

DC VOLTAGE :	Overload protection : 650V DC
400 mV	Resolution : 0.1 mV, Accuracy : +/- (1.0%rdg+3dgt)
4 V	Resolution 1 mV, Accuracy : +/- (1.0%rdg+3dgt)
40V	Resolution : 10 mV, Accuracy : +/- (1.0%rdg+3dgt)
400V	Resolution : 100 mV, Accuracy : +/- (1.0%rdg+3dgt)
600V	Resolution : 1 V, Accuracy : +/- (1.0%rdg+3dgt)
AC VOLTAGE :	Overload protection : 650V AC rms
400 mV	Resolution : 0.1 mV, Accuracy : +/- (2.0%rdg+3dgt)
4 V	Resolution : 1 mV, Accuracy : +/- (1.5%rdg+3dgt)
40 V	Resolution : 10 mV, Accuracy : +/- (1.5%rdg+3dgt)
400 V	Resolution : 100 mV, Accuracy : +/- (1.5%rdg+3dgt)
600 V	Resolution : 1 V, Accuracy : +/- (1.5%rdg+3dgt)
	Frequency Response : 0 ~ 400 mV at 40 Hz ~ 120 Hz, 4V ~ 600V at 40 Hz ~ 500 Hz
AC CURRENT
400 A	Resolution : 0.1 A, Accuracy : +/- (1.5%rdg+4dgt)
600 A	Resolution : 1 A, Accuracy : +/- (1.5%rdg+4dgt)
	Frequency Response : 40 Hz ~ 500 Hz
DC CURRENT
400 A	Resolution : 0.1 A, Accuracy : +/- (1.5%rdg+4dgt)
600 A	Resolution : 1 A, Accuracy : +/- (2.0%rdg+4dgt)

CEN0006 - 235 AC Leakage Clamp Meter

Our leakage clamp 235 has a very good resolution of 10uA. It is very useful for power system check and installation. With the measuring range up to 100A, it is also proper for indoor installation as a normal clamp meter so that the technician only have to bring one tester.
Features:

4 Digital Display.
10uA Resolution.
Autoranging.
Auto Power Off.
Max Hold Function.
Data Hold Function.
Auto Zero.

235 AC Leakage Clamp Meter

4 Digital Display.
10uA Resolution.
Autoranging.
Auto Power Off.
Max Hold Function.
Data Hold Function.
Auto Zero.

Specifications:

Standard Accessories:
Bettery, Operation Manual, Carrying Case, Test Lead.

PRO0021 Datalogging Power Clamp

Analysis for Single Phase and Balanced 3 phase system
True RMS Value (V and I)
Active Power (K,KW,MW,GW)
Apparent (VA,KVA,MVA) and Reactive Power (VAR,KVAR,MVAR)
Power Factor (PF), Phase Angle( Φ )
Energy (WH,KWH,KVARH,PFH)
Programmable PT(1 to 3000)Ratios
Display of Overlapped Voltage and Current Waveform
Maximum Demand (MD in W,KW,MW) with programmable Period
Harmonic Analysis (V and I) to 50th Order
Display of 25 Harmonics in one screen
Optical Isolated RS-232C Interface
Smart Datalogging to save Battery

Three-phase Power Clamp Meter

Graphic Power Quality Analyzer


Analysis for Single Phase and Balanced 3 phase system True RMS Value (V and I) Active Power (K,KW,MW,GW) Apparent (VA,KVA,MVA) and Reactive Power (VAR,KVAR,MVAR) Power Factor (PF), Phase Angle( Φ ) Energy (WH,KWH,KVARH,PFH) Programmable PT(1 to 3000)Ratios Display of Overlapped Voltage and Current Waveform Maximum Demand (MD in W,KW,MW) with programmable Period Harmonic Analysis (V and I) to 50th Order Display of 25 Harmonics in one screen Optical Isolated RS-232C Interface Smart Datalogging to save Battery	Datalogging of 32,64,128 or 256 points/cycles Analysis of Total Harmonic Distortion (%THD-F) Graphic Phasor Diagram Capture 128 Transient Events (Time+Cycles+Faults) with Programmable Threshold(%),also can be reviewed in LCD 50000 Records with Programmable Interval (1 to 6000 seconds) Real-time Output of Waveform, Power Parameters and Harmonics at Command Large Dot Matrix LCD Display with Backlight Power for Long-term Monitoring Built -in Calendar Clock for Data Logging

AC Current (50 or 60 Hz, Auto Range, True RMS)

Range	Resolution	Accuracy of Reading
4.0 V - 1500.0 A	0.01 A	± 0.5 % ± 5 dgts

AC Voltage (50 or 60 Hz, Auto Range, True RMS)

Range	Resolution	Accuracy of Reading
4.0 - 600.0 V	0.1 V	± 0.5 % ± 5 dgts

Harmonics of AC Voltage in Percentage and Magniude(1 to 50th order)

Range	Resolution	Accuracy (in%)	Accuracy (in Magnitude)
1 – 20 th	0.1 %	± 2 %	± 2 % ± 0.5 V
20 – 50 th	0.1 %	4 % of reading ± 2 %	4 % of reading ± 0.5 V

Harmonics of AC Current in Percentage and Magnitude (1 to 50th order)

Range	Resolution	Accuracy (in %)	Accuracy (in Magnitude)
1 – 20 th	0.1 %	± 2 %	± 2 % of reading ± 0.4 A
20 – 50 th	0.1 %	4 % of reading ± 2 %	± 4 % of reading ± 0.4A

Power Factor (PF)

Range	Resolution	Accuracy (>20 V and >20 A)
0.000 - 1.000	0.001	± 0.04

Phase Angle ( Φ )

Range	Resolution	Accuracy (>20 V and >20 A)
-180 ° to 180 ° (0 ° to 360 ° )	0.1 °	±1 °

Total Harmonic Distortion(%THD-F，1 to 50th order)

Range	Resolution	Accuracy (>20 V and >20 A)
0.0 - 20%	0.1%	± 2 %
20 - 100%	0.1%	± 6 % of reading ± 1 %
100 - 999.9%	0.1%	± 10 % of reading ± 1 %

Crest Factor (C.F.)

Range	Resolution	Accuracy of Readings
1.00 - 99.99	0.01	± 5 % ± 30 digits

AC Watt (50 or 60 Hz, PF 0.5 to 1, CT=1)

Range	Resolution	Accuracy of Readings (>20V and >20A)
10.0 - 999.9 W	0.1 W	± 1% ± 20 dgts
1.00 - 9.999 KW	0.001 KW	± 1% ± 20 dgts
10.00 - 99.99KW	0.01 KW	± 1% ± 20 dgts
100.0 - 999.9 KW	0.1 KW	± 1% ± 20 dgts
1000 - 9999 KW	1 KW	± 1% ± 20 dgts

General Specification:

Conductor Size	55mm(approx.), 64*24mm(bus bar)
Battery Type	Two 1.5 V SUM-3
Display	128*64 Dot Matrix
Power Consumption	10 mA (approx.)
Auto - Power - Off	30 minutes after power-on
Update time	2 times/sec. (display)
No. of Samples per Period	512 (voltage or current)，256 (power)
Operating Temperature	-10 ℃ to 50 ℃
Operating Humidity	<85% RH
Storage temperature	-20 ℃ to 60 ℃
Storage Humidity	<75% RH
Dimension	210 mm (L) * 62 mm (W) * 35.6 mm (H)，8.3"(L) * 2.5 "(W) * 1.4"(H)
Weight	Test leads 1 pair, Carrying bag1, Users manual1, Batteries 1.5V2
Accessories	640g

PRO0030 6830 3 Phase and 1 Phase Power,Power Factor and Harmonics Analyser

Analysis for 3P4W, 3P3W, 1P2W, 1P3W
True RMS Value (V 123 and L 123 )
Active Power (W, KW, MW, GW)
Apparent and Reactive Power (KVA, KVAR)
Power Factor (PF), Phase Angle (Φ)
Energy (WH, KWH, KVARH, PFH)
Current Measurement from 0.1mA to 3000A, Capable of Analyzing IT Standby Power Consumption to the Maximum Demand of a Factory
Display of 35 Parameters in One Screen(3P4W)
Programmable CT (1 to 600) and PT (1 to 3000) Ratios
Display of Overlapped Voltage and Current Waveform
2.4M Memory with Programmable Interval (1 to 6000 seconds, 17000 Records for 3P4W System)
Output of Waveform, Power Parameters and Harmonics at Command
Large Dot Matrix LCD Display with Backlight
Average Demand (AD in W, KW, MW)
Maximum Demand (MD in W, KW, MW) with Programmable Period
Harmonic Analysis to the 99th Order
Display of 50 Harmonics in One Screen with Waveform
Display of Waveform with Peak Values (1024 Samples/Period)
Analysis of Total Harmonic Distortion (%THD-F)
Graphic Phasor Diagram with 3 Phase System Parameters
Capture 28 Transient Events (Time + Cycles) with Programmable Threshold(%)
3 Phase Voltage Unbalance Ratio (VUR)
3 Phase Voltage Unbalance Factor (d0%, d2%)
Calculated Unbalance Current through Neutral Line (In)
Optical isolated USB Interface
Built-in Timer and Calendar for Data Logging
Conductor Size: -Model 6801 30mm(approx) -Model 6802 5
55mm(approx),64*24mm(bus bar) -Model 3007 170mm(approx)

TES-6800+3007

Analysis for 3P4W, 3P3W, 1P2W, 1P3W
True RMS Value (V 123 and L 123 )
Active Power (W, KW, MW, GW)
Apparent and Reactive Power (KVA, KVAR)
Power Factor (PF), Phase Angle (Φ)
Energy (WH, KWH, KVARH, PFH)
Current Measurement from 0.1mA to 3000A, Capable of Analyzing IT Standby Power Consumption to the Maximum Demand of a Factory
Display of 35 Parameters in One Screen(3P4W)
Programmable CT (1 to 600) and PT (1 to 3000) Ratios
Display of Overlapped Voltage and Current Waveform
2.4M Memory with Programmable Interval (1 to 6000 seconds, 17000 Records for 3P4W System)
Output of Waveform, Power Parameters and Harmonics at Command
Large Dot Matrix LCD Display with Backlight
Average Demand (AD in W, KW, MW)
Maximum Demand (MD in W, KW, MW) with Programmable Period
Harmonic Analysis to the 99th Order
Display of 50 Harmonics in One Screen with Waveform
Display of Waveform with Peak Values (1024 Samples/Period)
Analysis of Total Harmonic Distortion (%THD-F)
Graphic Phasor Diagram with 3 Phase System Parameters
Capture 28 Transient Events (Time + Cycles) with Programmable Threshold(%)
3 Phase Voltage Unbalance Ratio (VUR)
3 Phase Voltage Unbalance Factor (d0%, d2%)
Calculated Unbalance Current through Neutral Line (In)
Optical isolated USB Interface
Built-in Timer and Calendar for Data Logging
Conductor Size: -Model 6801 30mm(approx) -Model 6802 5
55mm(approx),64*24mm(bus bar) -Model 3007 170mm(approx)

* Please refer to users manual for more detailed and up-to-date description of specification

AC Watt (50 or 60 Hz, PF 0.5 to 1, CT=1)

Range	Resolution	Accuracy of Readings
Range	Resolution	6800+6801	6800+6802	6800+3007
5.0 – 999.9W	0.1W	±1% ± 8dgts	±1% ± 8dgts	±1% of VA Range ±8dgts
1.000 – 9.999 KW	0.001 KW	±1% ± 8 dgts	±1% ± 8 dgts	±1% of VA Range ±8dgts
10.00 – 99.99 KW	0.01 KW	±1% ± 8 dgts	±1% ± 8 dgts	±1% of VA Range ±8dgts
100.0 – 999.9 KW	0.1 KW	±1% ± 8dgts	±1% ± 8dgts	±1% of VA Range ±8dgts
1000 – 9999 KW	1 KW	±1% ± 8dgts	±1% ± 8dgts	±1% of VA Range ±8dgts
0.000 – 9.999MW	0.001MW	–	±1% ± 8 dgts	±1% of VA Range ±8dgts

AC Current( 50 or 60Hz, Auto Range，True RMS，Crest Factor<4，CT=1)　

	Range	Resolution	Accuracy of Readings
6800+6801 (Overload Protection AC200A)	0.050 – 9.999A	0.001A	±0.5% ± 5dgts
	10.00 – 60.00A	0.01A	±0.5% ± 5dgts
	60.00 – 99.99A	0.01A	±1.0% ± 5dgts
6800+6802 (Overload Protection AC2000A)	0.04 – 10.00A	0.01A	–
	0.4A – 100.0A	0.1A	±0.5% ± 5dgts
	4.0 – 1000.0A	1A	±0.5% ± 5dgts
6800+ 3007 (Overload Protection AC3500A)	4 – 300A	0.1A	±1% of Range ±5dgts
	300.0 – 999.9A	0.1A	±1% of Range ±5dgts
	1000 – 3000A	1A	±1% of Range ±5dgts

AC Voltage (50 or 60 Hz, Auto Range, True RMS, Crest Factor<4)

Range	Resolution	Accuracy of Readings	Range	Resolution	Accuracy of Readings
4.0V – 500.0 (Phase to Neutral)	0.1V	± 0.5% ± 5dgts	4.0V –600.0V (Phase to phase)	0.1V	± 0.5% ± 5dgts

Harmonics of AC Voltage in % and in Magnitude (1 to 99th order, minimum voltage at the 50 or 60 Hz>AC 80V)

Range	In Percentage		In Magnitude
Range	Resolution	Accuracy of readings	Resolution	Accuracy of readings
1 – 20 th	0.1%	±2%	0.1 V	±2% ±0.5V
21 – 49 th		4% of reading ±2.0%		4% of reading ±0.5A
50 – 99 th		6% of reading ±2.0%		6% of reading ±0.5A

Harmonics of AC Current in % and in Magnitude
Model 6800+6801(100A)(1 to 99th order, minimum current at 50 or 60 Hz is greater than 10% of the range)

Range	In Percentage		In magnitude
Range	Resolution	Accuracy of reading	Resolution	Accuracy of reading
1 – 10 th	0.1%	±0.2 of reading ±1%	0.1mA / 0.1A	±0.2% of reading ±7dgts
11 – 20 th		±2% of reading ±1%		±2% of reading ±7dgts
2 1 – 50 th (A range)		±5% of reading ±1%		±5% of reading ±7dgts
2 1 – 50 th (mA range)		±10% of reading ±1%		±10% of reading ±7dgts
5 1 – 99 th		±35% of reading ±1%		±35% of reading ±7dgts

Model 6800+6802(1000A);6800+3007(3000A)(1 to 99th order, minimum current at the 50 or 60 Hz>20A)

Range	In Percentage		In Magnitude
Range	Resolution	Accuracy of reading	Resolution	Accuracy of reading
1 – 20 th	0.1%	±2%	0.1A(6802) / 0.3A(3007)	±2% of reading ±0.4A/0.6A
21 – 49 th		4% of reading ±2.0%		±4% of reading ± 0.4A/0.6A
50 – 99 th		6% of reading ±2.0%		±6% of reading ± 0.4A/0.6A

Total Harmonic Distortion

Range	Resolution	Accuracy(6801)	Accuracy(6802)	Accuracy(3007)
0.0 – 20%	0.1%	±1%	±2%	±2%
20 – 100%	0.1%	±3% of reading ±5%	±6% of reading ±1%	±6% of Range ±1%
100 – 999.9%	0.1%	±10% of reading ±10%	±10% of reading ±1%	±10% of Range ±1%

Peak Value of Ac Voltage or AC Current ,VT=1

Range	Sampling Time	Accuracy of reading
50Hz	39 μS	±5% ±30digits
60Hz	33 μS	±5% ±30 digits

Crest Factor (C.F.) of ACV or ACA ,VT=1

Range	Resolution	Accuracy of reading
1.00 – 99.99	0.01	±5% ±30digits

Frequency in AUTO mode

Range	Resolution	Accuracy of reading
45 – 65Hz	0.1Hz	0.1Hz

Power Factor (PF)

Range	Resolution	Accuracy of reading
0.00 – 1.00	0.01	± 0.04

Phase Angle (Φ)

Range	Resolution	Accuracy of reading
-180 。 to 180 。	0.1 。	± 1 。

Conductor Size (6801)	30mm (approx.)
Conductor Size (6802)	55mm(approx.), 64 X 24mm(Bus Bar)
Battery Type	1.5V SUM-3 x 8
Display	Dot Matrix LCD with backlight
Power Consumption	140mA (approx.)
External DC Input	DC 12V adaptor (for safety purpose, the adaptor must be certified with 600Visolation protection)
LCD update rate	1 times / sec
No. Of Samples/Period	1024
Operating Humidity	< 85% relative
Operating Temperature	-10°C to 50°C
Storage Humidity	< 75% relative
Storage Temperature	- 20°C to 60°C
Weight(6800)	1160g
Weight(6801)	200g
Weight(6802)	600g
Dimension(6800)	257 (L) x 155 (W) x 57 (H) mm ,10.1"(L) x 6.1" (W) x 2.3" (H)
Dimension(6801)	210 (L) x 62 (W) x 36 (H) mm ,8.3 " (L) x 2.5" (W) x 1.4" (H)
Dimension(6802)	244 (L) x 97 (W) x 46 (H) mm ,9.6 " (L) x 3.8" (W) x 1.8" (H)
Accessories	Test leads x 4，alligator clips x 4，Carrying bag x 1，Users manual x 1，Batteries 1.5V x 8

MEASURE WITH CONFIDENCE WITH KKI

Pediatric dose of tylenol | World Wide Pills ссылка does ibuprofen have oxycodone in it avapro and celebrex interaction is ibuprofen poisonous to dogs is celebrex an anti inflammatory mixing cocaine and ibuprofen does tramadol contain acetaminophen vioxx and celebrex information what is tylenol made of acetaminophen crystals in urine is tylenol safe for pregnant women compounded hydrocodone low tylenol neurontin for restless leg syndrome neurontin without a prescription acetaminophen toxicity in cats dosing chart for infant tylenol does ibuprofen lower blood pressure can a dog have ibuprofen very bad side effect of celebrex difference between ibuprofen and acetaminophen celebrex blood in the urine difference between lyrica and neurontin neurontin dose for neuropathy celebrex contraindications risk vioxx can i take cipro and ibuprofen how much acetaminophen in hydrocodone
